The CC-10-120 is the latest turning roll design from Webb Corporation. The “CC” in CC-10-120, which stands for constant center, allows operators to easily adjust the roll to the product’s diameter by simply turning an adjustment wheel. This efficient design eliminates the need to remove bolts or change connecting shafts, saving valuable time when adjusting to changing material diameters. The CC-10-120 comes standard with a variable speed drive, forward-reverse-stop switch, rapid advance, and a potentiometer pendant control mounted to a 23-foot control cable. Additional cable lengths are also available.
| Total Turning Capacity(2 Idlers) in Tons | 15 |
| Turning Capacity(1 Idler) in Tons | 10 |
| Weight Capacity, Each Unit, in Tons | 5 |
| Motor Horsepower | 1/2 HP (2) |
| Voltage | 115V Standard 230V & 460V Optional |
| Speed Range, IPM | 4.5-42 |
| Wheel Face Width | 9” |
| Tires Per Axle | 2 |
| Maximum Working Diameter | 12’ |
| Minimum Working Diameter | 18” |
| Tire Diameter | 12” |
| Wheel Center Spacing | 18"-57" |
| Height to Top of Tire | 21” |
| Control Cable Length Optional (30’ Extension Available) | 20’ |
| Power Unit Length | 95-1/2” |
| Power Unit Width | 23” |
| Idler Unit Length | 78” |
| Idler Unit Width | 16“ |
| Power Unit Shipping Weight | 1130lbs |
| Idler Unit Shipping Weight | 800lbs |
| Total Shipping Weight (Approx.) | 1930lbs |
Power
Idler
